Digital Camera Exilim EX-Z85

Home : Products : Digital Camera : Exilim Series : EX-Z85



•	9.1 mega pixels, 3x optical zoom

•	Wide 2.6-inch LCD

•	Auto Shutter

•	Anti Shake DSP

•	Face Detection

•	easy Mode

•	Selectable focus frame and menu color

•	240-image Battery Life*1

•	30 BEST SHOT scenes

•	YouTube™ CAPTURE MODE

*1. Approximate; CIPA standards. (based on CASIO data)
• Screen and printed images shown in this catalog are simulations for explanatory purposes only. Actual images may appear different from those shown here.

EXILIM Zoom EX-Z85
Number of Effective Pixels			9.1 million
Image Sensor			1/2.5-inch square pixel CCD Total Pixels : 9.30 million
File Format	Still Images		JPEG (Exif Version 2.2, DCF 1.0 standard, DPOF compliant)
	Movies		MOV format, H.264/AVC, IMA-ADPCM (monaural)
	Audio (Voice Recording)		WAV format (monaural)
Built-in Flash Memory ( Image area )			41.2MB
Recording Media			SDHC Memory Card, SD Memory Card, MultiMediaCard, MultiMediaCardplus compatible
Number of Recorded Pixels	Still Images		3456 x 2592 3456 x 2304 (3:2) 3456 x 1944 (16:9) 3072 x 2304 2304 x 1728 1600 x 1200 640 x 480
	Movies		848 × 480 (WIDE, 30 fps) 640 × 480 (STD, 30 fps) 320 × 240 (LP, 15 fps)
Recording Capacity (when set at maximum image size)	Still Images	Built-in Flash Memory	Approx. 7 shots (Fine) 13 shots (Normal) 20 shots (Economy)
		SD Memory Card 1GB*1	Approx. 170 shots (Fine) 322 shots (Normal) 478 shots (Economy)
	Movies	Recording Time	Maximum recording time per file: 10 min.
		Built-in Flash Memory	Approx. 1 min. 13 seconds (WIDE)
		SD Memory Card 1GB*1	Approx. 30 min. 4 seconds (WIDE)
Operating Speed	Power on to First Shot23		Approx. 1.4 seconds
	Shutter Release Time Lag23		Approx. 0.008 seconds
	Image Playback		Approx. 0.1 second/image
	Shot to Shot Time34		Approx. 1.7 seconds
	Normal Speed Continuous Shutter*4		Approx. 1.1 second intervals
	High-Speed Continuous Shutter*5		Maximum is 5 frames per second
	Flash Continuous Shutter		Maximum is 3 frames per second
Lens	Construction		6 lenses in 5 groups, including aspherical lens
	F-number		F3.1 (W) to 5.9 (T)
	Focal Length		f= 6.3 to 18.6mm 35mm film equivalent : Approx. 38 to 114mm
Zoom	Optical Zoom		3X
	Digital Zoom		4X (12X in combination with optical zoom)
	HD Zoom		16X(640 x 480 pixels, both with optical and digital zoom)
Focusing	Focus Type		Contrast Detection Auto Focus
	Focus Modes		Auto Focus, Macro Mode, Pan Focus, Infinity Mode, Manual Focus
	AF Area		Spot, multi or tracking
Focus Range*6 (from lens surface)	Auto Focus		Approx. 40cm to ∞ (W)
	Macro		Approx. 10cm to 50cm (W)
	Infinity Mode		∞ (W)
	Manual Focus		Approx. 10cm to ∞ (W)
Exposure	Exposure Metering		Multi-pattern, center weighted, spot by imaging element
	Exposure Control		Program AE
	Exposure Compensation		-2EV to +2EV (in 1/3EV steps)
Shutter Type			CCD electronic shutter, mechanical shutter
Shutter Speed*7	Auto		1/2 to 1/2000 second
	Night Scene (BEST SHOT)		4 to 1/2000 second
Aperture*8			F3.1 (W) to F5.6 (W)*9, auto switching
White Balance			Auto WB, Daylight, Overcast, Shade, Day White FL, Daylight FL, Tungsten, Manual WB
Sensitivity (SOS/REI)*10	Still Images		Auto, ISO64, ISO100, ISO200, ISO400, ISO800, ISO1600
	Movies		Auto
Other Recording Functions	BEST SHOT		30 scenes
	YouTube™ Capture Mode		YES
	Face Detection		YES
	Auto Shutter		YES
	Voice Recording		YES
Self-timer			10 seconds, 2 seconds, Triple Self-timer
Built-in Flash	Flash Modes		Auto, Flash Off, Flash On, Soft Flash, Red Eye Reduction
	Flash Range		Normal: Approx. 0.1 to 2.6m (W), approx.0.6 to 1.4m (T)
			Flash continuous shooting: Approx. 0.4 to 1.4m (W), approx. 0.6 to 0.7m (T)
Monitor Screen			2.6-inch wide TFT color LCD, 114,960 dots (479×240)
Timekeeping Functions	Date and Time		Recorded with image data
	On-image Time Stamp Function		YES
	Auto Calendar		To 2049
	World Time		162 cities in 32 time zones, city name, date, time, summer time
Input/Output Terminals			USB/AV port
	USB		USB
Microphone			Monaural
Speaker			Monaural
Power Requirements			Rechargeable lithium ion battery (NP-60) x 1
Battery Life	Number of Shots*11		Approx. 240 still images (CIPA standards)
	Continuous Playback		Approx 4 hr. (still images)
	Continuous Recording		Approx. 4 hr. (voice recording)
Dimensions (excluding projections)			89.7 (W) x 51.7 (H) x 19.0 (D)mm Thinnest part: 17.8mm
Weight (excluding battery and accessories)			Approx. 100g
Bundled Accessories			Rechargeable lithium ion battery, lithium ion battery charger, AC power cord, USB cable, AV cable, strap, CD-ROM

*1. When using Panasonic (Matsushita) Pro High Speed 1GB SD Memory Card.
*2. When using built-in memory.
*3. With built-in flash off.
*4. When set at maximum image size and normal image quality.
*5. Image is fixed at 1600x1200 pixels and normal image quality.
*6. Range is affected by optical zoom.
*7. Shutter speed range may be different depending on the BEST SHOT scene.
*8. Using optical zoom causes the aperture to change.
*9. F5.6 is the aperture when an ND filter is being used.
*10. SOS: Standard Output Sensitivity. REI: Recommended Exposure Index.
*11. Auto Mode, standard brightness monitor setting.




All images shown here are simulations for explanatory purposes only. Actual images may appear different from those shown here.
